C12000 C12200 Copper Rod Polished Copper Nickel Round Bar

Place of Origin China
Brand Name SSZG
Certification ISO CE SGS ROHS
Model Number Copper Rod
Minimum Order Quantity 1 Ton
Price Negotiable
Packaging Details Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package
Delivery Time 3~10 days
Payment Terms L/C, T/T
Supply Ability 2000Tons per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Standard ASTM, AISI, JIS, DIN, GB, EN Shape Round
Surface Mill,polished,bright,oiled,hair Line,brush,mirror,sand Bla Application Building,War Industry, Car Industry And Communicationindustry
Temper Soft Annealed, Full Hard Type Copper Bars
High Light

C12000 Copper Rod

,

C12200 Copper Rod

,

Polished Copper Nickel Round Bar

Leave a Message
Product Description

C12000,C12200 Copper Bar / Copper Rod



Composition of Copper Rods



Copper rods are made primarily of copper, which is a chemical element with the symbol Cu and atomic number 29. Copper is a soft, malleable, and ductile metal that is reddish-orange in color and has excellent thermal and electrical conductivity.



Copper rods may also contain small amounts of other elements, such as:



Silver: Silver is sometimes added to copper rods to improve their conductivity and strength.



Phosphorus: Phosphorus is added to copper rods to make them more resistant to corrosion and improve their strength.



Oxygen: Oxygen is sometimes added to copper rods to improve their conductivity and reduce impurities.



Sulfur: Sulfur is added to copper rods to improve their machinability.



The exact composition of copper rods may vary depending on their intended use and manufacturing process. However, copper is the primary component, and any other elements are added in small amounts to improve specific properties.





Product Name Copper Bar
Grade ASTM
C10100,C10200,C10300,C10400,C10500,C10700,C10800,
C10910,C10920,C10930,C10940,C11000,C11300,C11400,
C11500,C11600,C12000,C12200,C12300,C12500,C14200,
C14420,C14500,C14510,C14520,C14530,C14700,C15100,
C15500,C16200,C16500,C17000,C17200,C17300,C17410,
C17450,C17460,C17500,C17510,C18700,C19010,C19025,
C19200,C19210,C19400,C19500,C19600,C19700,etc.
JIS
C1011,C1020,C1100,C1201,C1220,C1221,C1401,C1700,
C1720,C1990,etc.
EN
Cu-OFE, Cu-HCP, Cu-PHC, Cu-ETP, Cu-DHP, Cu-DLP;
CW009A, CW021A, CW020A, CW004A, CW024A, CW023A
DIN
OF-Cu, SE-Cu, E-Cu58, SF-Cu, SW-Cu.
Temper Soft, 1/4 Hard, 1/2 Hard, Hard, Extra Hard
Size Diameter: ≤ 500mm
Length: Straight ≤ 12000mm



Chemical Requirements
CU+AG (%) SN (%) ZN (%) PB (%) NI (%) FE (%) SB (%) S (%) AS (%) BI (%) O (%)
≥99.90 ≤0.002 ≤0.005 ≤0.005 ≤0.005 ≤0.005 ≤0.002 ≤0.005 ≤0.002 ≤0.001 ≤0.06



Alloy Chemical Composition
QB JIS /ASTM Cu P O Other
T2 JIS C1100 99.9 0.015-0.040 - balance
TU ASTM C10300 99.95 0.001-0.005 - balance
TP1 JIS C1220 99.9 0.004-0.012 - balance



Grade(China) Grade(Japan) Temper Vickers Hardness (HV) Tensile strength(Mpa) Elongation(%)
T2/T3/TP1/TP2 C11000/C1201 M - ≥290 ≥40
C1220.etc. Y4 75-125 325~410 ≥35
  Y2 85-145 340~460 ≥25
  Y 105-175 390~530 ≥13
  T - ≥490 -



C12000 C12200 Copper Rod Polished Copper Nickel Round Bar 0C12000 C12200 Copper Rod Polished Copper Nickel Round Bar 1C12000 C12200 Copper Rod Polished Copper Nickel Round Bar 2



C12000 C12200 Copper Rod Polished Copper Nickel Round Bar 3

Quality Control



C12000 C12200 Copper Rod Polished Copper Nickel Round Bar 4

Production Processing



C12000 C12200 Copper Rod Polished Copper Nickel Round Bar 5



Packing & Delivery



C12000 C12200 Copper Rod Polished Copper Nickel Round Bar 6



C12000 C12200 Copper Rod Polished Copper Nickel Round Bar 7





FAQ



1. Q: Are you a manufacturer?
A:Yes, we are manufacturers. We have our own factory and our own company. I believe we will be the most suitable supplier for you.


2. Q: Can we visit your factory?
A: Sure, we welcome you to visit our factory , check our production lines and know more about our strength and quality.


3. Q: Do you have quality control system?
A: Yes, we have ISO, BV, MTC, certifications and our own quality control laboratory.Third party testing services are also available


4. Q: Can you arrange the shipment for us?
A: Yes, we have designated sea freight and railway freight forwarders with decades of experiences and we get the best price with earlist vessel and professional service.


5. Q: How long is your delivery time?
A: Generally it is 7days if we have the exact goods in our stock. If not, it will take around 15-20 days to get goods ready for delivery.


6. Q: Can I get some samples?
A: We are glad to provide free samples to you, but we do not offer the freight.


7. Q: What is your after-sale service?
A: We provide after-sale service and offer 100% guarantee on our products.​
