Cu DHP Cu ETP Cu OFE Pure Copper Sheet Metal

Place of Origin China
Brand Name SSZG
Certification ISO CE SGS ROHS
Model Number Copper Sheet
Minimum Order Quantity 1 Ton
Price Negotiable
Packaging Details Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package
Delivery Time Within 7-10 Working Days
Payment Terms L/C, T/T
Supply Ability 5000 Ton/Tons per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Copper Sheet Material Brass ,Copper
Application Architecture , Electrical Wiring Processing Service Bending, Welding, Decoiling, Cutting, Punching
Tolerance 1%, 2%, 3%, Customize Cu (Min) 99%
High Light

Cu DHP Copper Sheet Metal

,

Cu ETP Copper Sheet Metal

,

Cu OFE copper sheet plate

Leave a Message
Product Description

Cu-DHP Cu-ETP Cu-OFE Pure Copper Plate



Advantages of copper plate


Excellent conductivity: Copper is one of the best conductors of electricity, making it an ideal choice for electrical applications.

High ductility: Copper is highly ductile, which means it can be easily formed into various shapes and sizes.



Corrosion-resistant: Copper has natural anti-corrosion properties, making it resistant to rust and other types of corrosion.

Good thermal conductivity: Copper is an excellent conductor of heat, making it ideal for heat transfer applications.



Aesthetic appeal: Copper has a beautiful reddish-brown color that makes it a popular choice for decorative and artistic applications.



Low maintenance: Copper requires minimal maintenance, and it is highly durable, making it a cost-effective material in the long run.



Biostatic properties: Copper has antimicrobial properties that help to prevent the growth of bacteria and other microorganisms, making it an ideal choice for applications where cleanliness is crucial, such as in healthcare settings.



Overall, the advantages of copper plates make them a popular choice for a wide range of applications, from electrical wiring and plumbing to decorative arts and sculpture.



Product Name Copper Plate/Sheet
Material Copper
Standard ASTM, AISI, JIS, DIN, GB, EN
Grade  TP1,TP2,C10930,C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300,TU1,TU
2C12500,C14200,C14420,C14500,C14510,C14520,C14530,C17200,C19200,C21000,C23000
C26000,C27000,C27400,C28000,C33000,C33200,C37000,C44300,C44400,C44500,C60800
C63020,C65500,C68700,C70400,C70600,C70620,C71000,C71500,C71520,C71640,C72200,etc
Shape Flat plate
Size Thickness 0.3mm~100mm;Width 50mm~2500mm; Length 1000mm~12000mm
Surface Mill finish, polished, anodizing, brushing,sand blasting, powder coating,etc
Payment terms T/T,L/C,western union, Paypal
Price terms CFR,FOB,CIF,Ex-work,CNF
Application 1)Further making utensil.
2)Solar reflective film
3)The appearance of the building
4)Interior decorating:ceilings,walls,etc.
5)Furniture cabinets
6)Elevator decoraction
7)Signs,nameplate,bags making.
8)Decorated inside and outside the car
9)Household appliances:refrigerators,microwave ovens,audio equipment,etc.
10)The consumer electronics:mobile phones,digital cameras,MP3,U disk,etc.
Package Standard export seaworthy package or as required.
Contact If you have any question,please feel free to contact me.



Material China GB/T Japan JIS German DIN American ASTM UK EN
TU0 C1011 -- C10100 C110
TU1 C1020 OF-CU C10200 C103
TU2 C1020 OF-CU C10200 C103
T1 C1020 OF-CU C10200 C103
T2 C1100 SE-CU C11000 C101
TP1 C1201 SW-CU C12000 --
TP2 C1220 SF-CU C12000 --



Composition(%)
TU1 Cu P O Other
TU2 99.97 0.002 less than 0.002 balance
T1 99.95 0.002 less than 0.003 balance
T2 99.9 - - balance
TP1 99.9 0.004-0.012 - balance
TP2 99.9 0.015-0.040 - balance
C10200 99.95 0.001-0.005 - balance
C11000 99.9 - - balance
C12000 99.9 0.004-0.012 - balance
C12200 99.9 0.015-0.040 - balance



Cu DHP Cu ETP Cu OFE Pure Copper Sheet Metal 0Cu DHP Cu ETP Cu OFE Pure Copper Sheet Metal 1Cu DHP Cu ETP Cu OFE Pure Copper Sheet Metal 2Cu DHP Cu ETP Cu OFE Pure Copper Sheet Metal 3Cu DHP Cu ETP Cu OFE Pure Copper Sheet Metal 4



Production Processing



Cu DHP Cu ETP Cu OFE Pure Copper Sheet Metal 5



Packing & Delivery

Cu DHP Cu ETP Cu OFE Pure Copper Sheet Metal 6



Cu DHP Cu ETP Cu OFE Pure Copper Sheet Metal 7





FAQ


Q: Do you provide free samples?
A: Yes, we can provide a free sample for testing,buyer should bear all the shipping costs.



Q:Do you accept small orders?
A:You don't need to worry about this problem, just consult



Q: Do you accept the third party inspection?
A: Yes absolutely we accept.



Q: How could you guarantee your products?
A: Each piece of products is manufactured by certified workshops, inspected by Linxu piece by piece according to national QA/QC
standard. We also could issue the warranty to customer to guarantee the quality.



Q:What are the advantages of your company?
A:
(1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Trial order can be done in one week.
(6): Samples can be provided as your requirements.



Q:What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance based on BL copy or LC at sight.



Q:How about our price?
A:Our price is very competitive because we are a factory.
Pls feel free to contact us if you are interested in our products.



Q:How long is your delivery time?
A:Different products have different delivery time.The products will be delivered as soon as possible on the basis of the quality

assurance.Usually the delivery time is within 7 days after we received your deposit.



Please leave your enquiry in the message box at the bottom of the product page and click SEND, we will contact you as soon as
possible !
